10G EML BIDI BOSA 1490T/1550R

The 10Gb/s transmitter optical subassembly integrates a high-speed electlro-absorption modulated laser (EML), a micro-TEC and monitor PD in a small form-factor metallized ceramic package. It is designed for use in small form-factor pluggable transceivers and other types of optical modules for high-speed telecommunication and data applications including SONET OC-192, SDH STM-64 and 10Gigabit Ethernet.

  1. Ultra small form-factor 8-pin
  2. Data rates up to 10.7Gb/s
  3. For use up to 40km & 80km at 10Gb/s
  4. Temperature stabilized
  5. Very low TEC power consumption
  6. 50Ω single-ended data input
  7. Case operating temperature range: -40℃ to 85℃.
