Wide Bandwidth
Incorporated Bias-T
DC Coupled
Hermetically Sealed, 2.92 Connector
The MD1002 high-speed detector module is designed for both digital and analog applications. The module contains an InGaAs PIN photodiode which response wavelength covers 1250 to 1650 nm and necessary matching electronics.
MD1002 can provide the bandwidth of 30 GHz , 40 GHz. The module operates on +4V. It complies with a standard single-mode 9/125μm fiber input. The RF output port is an 2.92 mm connector matched by 50 ohm impedance .
MD1002 is hermetically sealed, and weighs less than 20 grams.
ROHS 2.0 certificated .
Wide Bandwidth
Incorporated Bias-T
DC Coupled
Hermetically Sealed, 2.92 Connector
